NVM 50.00.021 Koolhoven FK46 trainer

Artikelnummer: 50.00.021

Koolhoven F.K.46Ì´Ì_

Bron : www.wikipedia.org/wiki/Koolhoven_F.K.46

The Koolhoven F.K.46 was a 1930s Dutch training biplane designed and built by Koolhoven.

The F.K.46 was a two-seat biplane with fixed tailwheel landing gear and tandem open cockpits. The prototype first flew in 1933 powered by a Cirrus Hermes engine. A second prototype was fitted with a sliding cockpit canopy. The aircraft entered limited production and four were used by the Nationale Luchtvaart School (Dutch National Flying School). One aircraft was evaluated by the Dutch Army. In 1935 a reduced weight version designated F.K.46L was built powered by a 95 hp (71 kW) Walter Minor engine but only one was built.

Most of the F.K.46s did not survive the German-invasion in May 1940, although one was sent to South Africa for an evaluation by the South African Air Force although it was expensive compared with the de Havilland Tiger Moth. The surviving aircraft was later impressed into service with the South African Air Force.

Operators

NetherlandsNationale Luchtvaart School

South Africa South AfricaSouth African Air Force

Specifications.

General characteristics

  • Crew: 2
  • Length: 7.30 m (23 ft 11Ì´_ in)
  • Wingspan: 8 m (26 ft 3 in)
  • Gross weight: 870 kg (1918 lb)
  • Powerplant: 1 ÌÎÌÔ de Havilland Gipsy Major, 97 kW (130 hp)

Performance

  • Maximum speed: 175 km/h (109 mph)


Specificaties Modelbouwtekening :

Tekeningnummer

50.00.021

Auteur

C. ter Horst

Omschrijving

Koolhoven FK46 trainer

Kwaliteit

Ì´Ì_

Moeilijkheidsgraad

D

Schaal

1 : 20

Aantal bladen A00

0

Aantal bladen A0

0

Aantal bladen A1

0

Aantal bladen A2

2

Aantal bladen A3

0

Aantal bladen A4

0

Totaal aantal bladen tekening

2

Aantal bladen A4 tekst

0

Gewicht in gram

65

Bijzonderheden

spanwijdte 40 cm

dM 2001/7,9, 2002/9

Kopie artikel: 52.00.021 (10 blz)

Opmerkingen

Ì´Ì_
0 sterren gebaseerd op 0 beoordelingen
