| Article number: | 40.30.036 |
Specifications :
|
Drawing number |
40.30.036 |
|
Author |
J. Thompson |
|
Description |
buckboard |
|
Quality |
C |
|
Difficulty level |
Ì´Ì_ |
|
Scale |
1 : 8 |
|
Number of sheets A00 |
0 |
|
Number of sheets A0 |
0 |
|
Number of sheets A1 |
0 |
|
Number of sheets A2 |
0 |
|
Number of sheets A3 |
4 |
|
Number of sheets A4 |
0 |
|
Total number of drawing sheets |
4 |
|
Number of A4 text sheets |
4 |
|
Weight in grams |
95 |
|
Details |
dM 1988/10 |
|
Remarks |
check number of sheets Ì´Ì_
|
