MBT 60.01.054 CD-Twin-cylinder oscillating piston steam engine; drawings and animations

Drawing number

60.01.054

Author

J.A.M. de Waal

Description

CD-Twin-cylinder oscillating piston steam engine; drawings and animations

Quality

Difficulty level

D

Scale

n/a

Number of sheets A00

0

Number of sheets A0

0

Number of sheets A1

0

Number of sheets A2

0

Number of sheets A3

0

Number of sheets A4

0

Total number of drawing sheets

0

Number of A4 text sheets

0

Weight in grams

0

Special features

dM 2008/10

Copy article: 62.01.054 (3 pp)

An experimental machine

CD contains drawings in Solid Works format and .pdf format

Remarks

include main dimensions
