MBT 60.01.031 3-cylinder steam engine with Hackworth valve gear

Drawing number

60.01.031

Author

M. van Westendorp

Description

3-cylinder steam engine with Hackworth valve gear

Quality

detailed model engineering drawing

Difficulty level

D

Scale

N/A

Number of A00 sheets

0

Number of A0 sheets

0

Number of A1 sheets

0

Number of A2 sheets

0

Number of A3 sheets

7

Number of A4 sheets

0

Total number of drawing sheets

7

Number of A4 text sheets

0

Weight in grams

165

Special features

based on original drawing by A. Zevenhuizen.

dM 1991/1,3,6,10

Article copy: 62.01.031 (11 pages)

Dimensions in the article may differ from those on the drawing as errors in the original drawing have been corrected.

Remarks
