| Article number: | 60.10.022 |
|
Drawing number |
60.10.023 |
|
Author |
J.A.M. Ridders |
|
Description |
1-Cylinder duo 4-stroke engine with opposed pistons, metal cylinder and rotary valve |
|
Quality |
detailed model building drawing with construction description |
|
Scale |
n/a |
|
Number of sheets A00 |
0 |
|
Number of sheets A0 |
0 |
|
Number of sheets A1 |
0 |
|
Number of sheets A2 |
0 |
|
Number of sheets A3 |
0 |
|
Number of sheets A4 |
9 |
|
Number of A4 text sheets |
4 |
|
Weight in grams |
100 |
|
Special features |
A design with two opposed pistons in one cylinder and a rotary exhaust valve |
|
Remarks |
