| Article number: | 16.11.038 |
Specifications :
|
Drawing number |
16.11.038 |
|
Description |
HrMs submarine "O 15" (1932) |
|
Quality |
12 frame sections; side view 1:1:50 |
|
Difficulty level |
D |
|
Scale |
1 : 25 |
|
Number of sheets A00 |
3 |
|
Number of sheets A0 |
0 |
|
Number of sheets A1 |
0 |
|
Number of sheets A2 |
0 |
|
Number of sheets A3 |
0 |
|
Number of sheets A4 |
0 |
|
Total number of drawing sheets |
3 |
|
Number of A4 text sheets |
0 |
|
Weight in grams |
185 |
|
Particulars |
l.o.a. 240cm |
|
Remarks |
