MBT 20.20.001 steam locomotive T16-1 (BR94) (DB) for 5" gauge

Drawing number

20.20.001

Author

J. Leendertse

Description

steam locomotive T16-1 (BR94) (DB) for 5" gauge

Quality

fully detailed model engineering drawing

Difficulty level

D

Scale

1 : 11

Number of A00 sheets

0

Number of A0 sheets

1

Number of A1 sheets

7

Number of A2 sheets

22

Number of A3 sheets

2

Number of A4 sheets

0

Total number of drawing sheets

32

Number of A4 text sheets

0

Weight in grams

845

Special features

dM 2012/9,10

copy article: 22.20.001 (8 pages)

The boiler complies with the inspection regulations as of 1-1-2013 and is designed for 6 Bar working pressure

Remarks
