MBT 20.20.005 Crampton locomotive; for 5"-gauge (127 mm)

Drawing number

20.20.005

Author

J.C.W.Ì´Ì_Steffers

Description

Crampton locomotive; for 5"-gauge (127 mm)

Quality

detailed construction drawing with many construction and machining instructions

Difficulty level

D

Scale

1 : 11.5

Number of A00 sheets

0

Number of A0 sheets

0

Number of A1 sheets

0

Number of A2 sheets

0

Number of A3 sheets

49

Number of A4 sheets

3

Total number of drawing sheets

52

Number of A4 text sheets

0

Weight in grams

515

Special features

Based on original design by Brian Arridge

Drawing set includes boiler drawing

The construction description of this loco appeared in "Onder Stoom", 1997 to 2002

5" gauge (127 mm); coal-fired; 6 bar; cyl. Bore x stroke 35 x 50.8 mm; driving wheel dia. 177.8 mm

Remarks

include translation of instructions for Germany
